UA-3

Angle Adapter, universal, snap-in, 3/4 in through hole
Specifications
Finish making your selections or clear them to view relevant specifications.
How to Buy
Specifications

Product Classification

Product Type Adapter
Ordering Note CommScope® standard product in the United States and Canada | CommScope® standard product in Asia Pacific

General Specifications

Adapter Type Angle adapter
Mounting 3/4 in through hole

Dimensions

Inside Width 0.88 in | 22.352 mm
Outside Width 2.25 in | 57.15 mm
Inside Length 1 in | 25.4 mm
Outside Length 2 in | 50.8 mm
Material Thickness 0.105 in | 2.667 mm

Material Specifications

Material Type Stainless steel

Mechanical Specifications

Installation Torque, maximum 15 ft lb | 20.337 N-m
Installation Torque, minimum 11 ft lb | 14.914 N-m
Maximum Loading Triple stack, 1-5/8 in cable

Packaging and Weights

Height, packed 25 cm | 9.843 in
Width, packed 14 cm | 5.512 in
Length, packed 12 cm | 4.724 in
Packaging quantity 10
Weight, gross 2.32 kg | 5.115 lb

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
ROHS ROHSCompliant
CHINA-ROHS CHINA-ROHSBelow maximum concentration value
REACH-SVHC REACH-SVHCCompliant as per SVHC revision on www.commscope.com/ProductCompliance

Product Classification

Product Type Adapter
Ordering Note CommScope® standard product in the United States and Canada | CommScope® standard product in Asia Pacific

General Specifications

Adapter Type Angle adapter
Mounting 3/4 in through hole

Dimensions

Inside Width 0.88 in | 22.352 mm
Outside Width 2.25 in | 57.15 mm
Inside Length 1 in | 25.4 mm
Outside Length 2 in | 50.8 mm
Material Thickness 0.105 in | 2.667 mm

Material Specifications

Material Type Stainless steel

Mechanical Specifications

Installation Torque, maximum 15 ft lb | 20.337 N-m
Installation Torque, minimum 11 ft lb | 14.914 N-m
Maximum Loading Triple stack, 1-5/8 in cable

Packaging and Weights

Height, packed 25 cm | 9.843 in
Width, packed 14 cm | 5.512 in
Length, packed 12 cm | 4.724 in
Packaging quantity 10
Weight, gross 2.32 kg | 5.115 lb

Regulatory Compliance/Certifications

Agency
ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
ROHSCompliant
CHINA-ROHSBelow maximum concentration value
REACH-SVHCCompliant as per SVHC revision on www.commscope.com/ProductCompliance
