CK1828-001 | TEL-SPLICE II Y2F

  • Available in:
  • Asia
  • Australia/New Zealand
  • EMEA
  • Latin America

Tel-Splice II Connector, 2-wire, gel filled, yellow

Specifications
Finish making your selections or clear them to view relevant specifications.
Find a Partner
Features and Benefits
  • Complete reliable, gas-tight connection between the contact and conductor
  • Lightweight, compact, and economical means of splicing multiconductor telephone cable

Product Classification

Regional Availability Asia | Australia/New Zealand | EMEA | Latin America
Product Type Butt splice connector
Product Series Tel-Splice II
Ordering Note Minimum order quantity, 10000 parts

General Specifications

Connector Sealant Gel filled
Transmission Standards IEC 60068-2 | IEC 60512-4

Dimensions

Compatible Insulated Conductor Diameter, maximum 2.08 mm | 0.082 in
Compatible Conductor Gauge, solid 26–19 AWG

Electrical Specifications

Contact Resistance, maximum 30 ohm
Dielectric Strength 1.4 kV
Insulation Resistance, minimum 100 mOhm

Material Specifications

Contact Base Material Phosphor Bronze
Contact Plating Material Tin

Mechanical Specifications

Axial Tensile Strength, maximum 118N @ 0.9 mm wire | 52N @ 0.4 mm wire

Environmental Specifications

Operating Temperature -30 °C to +70 °C (-22 °F to +158 °F)
Environmental Space Outdoor

Packaging and Weights

Packaging quantity 100
Packaging Type Box | Carton
